Body PIR Motion Sensor Switch Auto Delay For LED Strip Light

Place of Origin : China

Certification : CE

Packaging Details : 200pcs/box

Price : negotiation

Model Number : Sensor switch

MOQ : negotiation

Payment Terms : T/T

Supply Ability : 10000pcs/month

Delivery Time : 3-10days

Warranty(Year) : 1-Year

Type : Sensor switch

Max. Load Power : 60W

Connection Mode : DC Port

Product name : PIR Sensor Switch

Application : Low voltage LED strip

Function : Photosensitive switch ; Delay off adjustment

Voltage : DC5V DC12V DC24V

Keyword : LED PIR infrared body sensor switch controller

Output power : 5V 20W ; 12/24V 60W

Detecting range : 0 . 2-3m

Delay Time : 30s 60s 300s

Contact Now

Body PIR Sensor Switch Motion Sensing Auto Delay For LED Strip Light

DC 5-24V PIR Sensor Switch
Place sensor directly to motion range of peopleLight will on when detect motion, light off whenthere is no motion detected within a delay time
Basic Features:
1. Automatically adapts input voltage DC5V-24V
2.Delay time is adjustable by switch
3.Light sensor is optional by switch
4.Small size with 140 degree large detectingangle

Specifications:
Model	PIR-DC524-5A
Voltage	DC 5V/12V/24V
Maximum load	5V 20W, 12/24V 60W
Detection range	0.2-3m
Delay time	30s 90s 300s
Function	The light is on when there is motion, and the light turns off in the delay time when motion is detected

Product Package:

PIR Sensor Switch*1PCS 3M Adhesive Backing*1PCS User Manual*1PCS

Product Description

Body PIR Motion Sensor Switch Auto Delay For LED Strip Light
